Cisco ASA: VPNs With Overlapping Subnets
KB ID 0001446 Problem I’ve seen this pop up a few times in forums, and I’ve even seen people post “It cant be done, you will need to change one of the subnets,”  but to be honest, it’s not that difficult. We simply have to do some NAT. This is the bit people struggle with, with VPNs usually we need to STOP NAT being applied to VPN traffic, and we still do, we simply NAT the traffic before we sent it over the tunnel. Normally overlapping networks can trip you up, in one of TWO scenarios; Scenario 1 (The other end overlaps with YOU) Scenario 2 (Two endpoints overlap with EACH OTHER) Solution Scenario 1 (The other end overlaps with YOU) Firstly you need to pick another subnet for BOTH ends, and this is the subnet the other end will THINK it’s talking to, sometimes this is called an XLATED subnet, or a PSEUDO subnet, or a MASQUERADE subnet. ASA-1 Config Firstly we need THREE objects creating, (instead of the usual TWO). Then take note the syntax of the NAT statement; ! object network OBJ-Site-A subnet 192.168.1.0 255.255.255.0 object network OBJ-Site-A-XLATE subnet 172.16.1.0 255.255.255.0 object network OBJ-Site-B-XLATE subnet 172.16.2.0 255.255.255.0 ! nat (inside,outside) source static OBJ-Site-A OBJ-Site-A-XLATE destination static OBJ-Site-B-XLATE OBJ-Site-B-XLATE ! Note: Above, I’m assuming your interfaces are called inside and outside! Now you need to create the ACL that will be used to define ‘interesting traffic’, i.e. traffic that will be encrypted, but unlike normal you will specify the XLATED addresses. ! access-list VPN-INTERESTING-TRAFFIC line 1 extended permit ip object OBJ-Site-A-XLATE object OBJ-Site-B-XLATE ! The rest of the VPN config is the same as normal, here I’m using IKEv2. If you have to use IKEv1 see the link at the bottom of the page. ! crypto ikev2 policy 10 encryption aes-256 integrity sha256 group 19 prf sha256 lifetime seconds 86400 crypto ikev2 enable outside ! tunnel-group 2.2.2.2 type ipsec-l2l tunnel-group 2.2.2.2 ipsec-attributes pre-shared-key 1234567 ikev2 remote-authentication pre-shared-key 1234567 ikev2 local-authentication pre-shared-key 1234567 isakmp keepalive threshold 10 retry 2 ! crypto ipsec ikev2 ipsec-proposal VPN-TRANSFORM protocol esp encryption aes-256 protocol esp integrity sha-1 ! crypto map CRYPTO-MAP 1 match address VPN-INTERESTING-TRAFFIC crypto map CRYPTO-MAP 1 set peer 2.2.2.2 crypto map CRYPTO-MAP 1 set ikev2 ipsec-proposal VPN-TRANSFORM crypto map CRYPTO-MAP interface outside ! WARNING: If you already have VPNs then change CRYPTO-MAP (above) to the name of your existing crypto map. ASA-2 Config As with most site to site VPN configs, the ‘other-end’ should be a mirror image, like so; ! object network OBJ-Site-B subnet 192.168.1.0 255.255.255.0 object network OBJ-Site-B-XLATE subnet 172.16.2.0 255.255.255.0 object network OBJ-Site-A-XLATE subnet 172.16.1.0 255.255.255.0 ! nat (inside,outside) source static OBJ-Site-B OBJ-Site-B-XLATE destination static OBJ-Site-A-XLATE OBJ-Site-A-XLATE ! access-list VPN-INTERESTING-TRAFFIC line 1 extended permit ip object OBJ-Site-B-XLATE object OBJ-Site-A-XLATE ! crypto ikev2 policy 10 encryption aes-256 integrity sha256 group 19 prf sha256 lifetime seconds 86400 crypto ikev2 enable outside ! tunnel-group 1.1.1.1 type ipsec-l2l tunnel-group 1.1.1.1 ipsec-attributes pre-shared-key 1234567 ikev2 remote-authentication pre-shared-key 1234567 ikev2 local-authentication pre-shared-key 1234567 isakmp keepalive threshold 10 retry 2 ! crypto ipsec ikev2 ipsec-proposal VPN-TRANSFORM protocol esp encryption aes-256 protocol esp integrity sha-1 ! crypto map CRYPTO-MAP 1 match address VPN-INTERESTING-TRAFFIC crypto map CRYPTO-MAP 1 set peer 1.1.1.1 crypto map CRYPTO-MAP 1 set ikev2 ipsec-proposal VPN-TRANSFORM crypto map CRYPTO-MAP interface outside ! WARNING: If you already have VPNs then change CRYPTO-MAP (above) to the name of your existing crypto map.  Scenario 2 (Two endpoints overlap with EACH OTHER) Firstly you need to pick another subnet for BOTH of the ends with the overlapping subnet, and this is the subnet that your end will THINK it’s talking to, sometimes this is called an...
