Public Folder Migration Error hr=0x80040111

KB ID 0001228 Dtd 05/08/16


I usually follow my own documented process for migrating public folders to Exchange 2016. I did that this week, and this happened;

Public Folder Migration Error


MapiExceptionLogonFailed: Unable to make connection to the server. (hr=0x80040111, ec=-2147221231)
Diagnostic context:
    Lid: 49064   dwParam: 0x1
    Lid: 37288   StoreEc: 0x6AB
    Lid: 49064   dwParam: 0x2
    Lid: 49191   EMSMDBMT.EcDoConnectEx called [length=178]
    Lid: 48679   EMSMDBMT.EcDoConnectEx returned [ec=0x80040111][length=56][latency=0]
    Lid: 45169   StoreEc: 0x80040111
    Lid: 50544   ClientVersion:
    Lid: 52080   StoreEc: 0x80040111
    Lid: 1494    ---- Remote Context Beg ----
    Lid: 22086
    Lid: 27206
    Lid: 39869
    Lid: 56893   StoreEc: 0x8004010F
    Lid: 44989
    Lid: 24684
    Lid: 20076   StoreEc: 0x80040111
    Lid: 29100
    Lid: 20396   StoreEc: 0x80040111
    Lid: 9486    StoreEc: 0x80040111
    Lid: 24492
    Lid: 18348   StoreEc: 0x80040111
    Lid: 26540   dwParam: 0xE0003
    Lid: 22444   dwParam: 0xC30001
    Lid: 1750    ---- Remote Context End ----
    Lid: 51152
    Lid: 52465   StoreEc: 0x80040111
    Lid: 60065
    Lid: 33777   StoreEc: 0x80040111
    Lid: 59805
    Lid: 52487   StoreEc: 0x80040111
    Lid: 19778
    Lid: 27970   StoreEc: 0x80040111
    Lid: 17730
    Lid: 25922   StoreEc: 0x80040111
    + CategoryInfo          : NotSpecified: (:) [New-PublicFolderMigrationRequest], RemoteTransientException
    + FullyQualifiedErrorId : [Server={New-Server},RequestId=6cbefa76-98ad-4a2e-bb33-237d7fd795fd,TimeStamp=03/08/2016 7:1
   7:17 PM] [FailureCategory=Cmdlet-MapiExceptionLogonFailed] 42728F13,Microsoft.Exchange.Management.Migraion.NewMgrationBatch
    + PSComputerName        : {new-server}


Although it looks a pretty scary error, it’s quite straightforward to rectify. I was doing a migration and I’d moved all the mailboxes already, so I had dismounted and removed the mailbox database on the source Exchange server. (Exchange 2010). All I had to to was mount a mailbox database (I just created a new empty one, and mounted it.)

Create Mailbox Database

If I then tried to do the migration, it queued up properly!

PF Migration Request
